CS80 Carbon Spring Steel - High Strength Spring Steel

CS80 Carbon Spring Steel is a high-carbon spring steel grade defined within BS1449.
It is closely equivalent to C75S, AISI/SAE 1075, and closely matches EN42.

Known for its strength, wear resistance, and resilience, CS80 is widely used in the manufacture of flat springs, knives, and industrial blades. Historically difficult to cut, modern laser and water jet cutting methods now make CS80 much easier to process, driving its popularity across engineering and manufacturing sectors.

CS80 Carbon Spring Steel Chemical Composition

CS80 Spring Steel

Carbon – 0.75 – 0.85%
Manganese – 0.5 – 0.9%
Silicon – 0.05 – 0.35%
Phosphorous – 0.045% max
Sulphur – 0.045% max

CS80 Carbon Spring Steel Equivalent grades

C75S
AISI / SAE 1075
EN42

Applications of CS80 Spring Steel

CS80 is a strong, reliable material used in:

Flat springs
Knives and cutting blades
Machine components requiring wear resistance

Thanks to modern laser and water jet cutting, CS80 is now easier to process into complex profiles and precision components.

CS80 Carbon Spring Steel - Condition Supplied

BSS supply CS80 Spring Steel in the hardened and tempered condition.

Our CS80 Carbon Spring Steel Range

At BSS Spring Steel Stock, CS80 is supplied in:

Hardened and tempered condition
Coil form up to 2.00mm gauge
Sheet stock from 0.25mm to 1.00mm gauge
We supply CS80 Spring Steel in the hardness range is 400/440vpn.

Our CS80 is precision rolled, ensuring excellent surface finish, tight thickness tolerances, and reliable flatness

Our material is precision rolled with a good surface finish, close thickness tolerance and good flatness.

N.B. We do not supply Mill Certificates with orders, we only supply Certificates of Conformity.

Why Choose BSS for CS80?

📦 Large UK stockholding for fast delivery
🛠️ Cut-to-size service available
✅ ISO9001 certified quality assurance
🔍 Decades of experience in Spring Steel Supply
